IRIS MXTM

The Iris MX from RDI Technologies expands upon its revolutionary Iris M™ product to open up the world of Motion Amplification® to high-speed applications. With up to 1400 FPS in HD resolution, you can now apply Motion Amplification® and communicate virtually every displacement in the scene.

Leveraging a high-speed camera for frame rates over 10,000 fps, the Iris MX's most unique capability is the ability to apply Motion Amplification® and show motions well over 5,000 Hz and produce an infinite amount of absolute measurements within the scene. The Iris MX enables the user to see the fault by visualizing the motion of the entire machine, its structure and base, and surrounding environment to determine the root cause. This enables the users to quickly and comprehensively diagnose machinery in a simple and easy-to-understand video. This video can be used to close the communication gap between technical and non-technical resources and empowers them to fix problems. The Iris MX is high-level analysis in its' simplest form.

Visualize

Motion Amplification® is a proprietary video processing technique that detects subtle displacement and then converts that movement to a level visible with the naked eye.

Measure

Iris MX™ measures and quantifies mechanical or structural assets that a camera can see with the same accuracy as a contacting displacement sensor.

Troubleshoot

Iris MX™ allows you to filter your data and visualize movement at specific frequencies to find the real source of a problem and help position your team to fix it.

Communicate

Iris MX™ enhances understanding of components and interrelationships creating movement and provides a communication tool for technical and non-technical resources.

SOFTWARE

Motion Amplification® Acquisition

RDI’s Motion Amplification® Acquisition Software’s user interface is as simple as point and click. This allows you to instantly visualize and measure movement at 2.3 million video-based sensor points.

Motion Amplification® Analysis

RDI’s Motion Amplification® Analysis Software makes complex asset analysis as simple as point and shoot. Each simple video taken in the acquisition software can now be used to extract time waveforms, spectra, and orbits or for complex processes like frequency based filtering, shaft inspection, and much more.

Motion Studio™

The new Motion Studio Update gives you the ability to create more powerful videos with RDI’s Motion Amplification® software. Add spectra and waveforms to your videos, show multiple views from a single screen, and edit your videos straight from video editor screen. Motion Studio gives you all the tools for your reports.

Motion Explorer™

All of this data needs somewhere to live in an organized and simple to access format. Motion Explorer is a comprehensive file management tool that keeps all your data organized, accessible, and ready for further analysis at any point in time.

videos straight from video editor screen. Motion Studio gives you all the tools for your reports.

Motion Amplification®

See motion invisible to the naked eye in near real-time view.

Up to 1400 FPS in Full HD Resolution

up to 29,000 fps at reduced resolution.

Group 9 Created with Sketch.

Calibrated Displacement Measurements

<0.01 mils (0.25 μm) at 3.3 ft (1m) with 50mm lens, 0.005 mils (0.125 μm) at close focus.

Group 11 Created with Sketch.

Available as an Add On

The MX camera is an add on the Iris M basic system and must be purchase either as a combined unit or as an add on to an existing Iris M unit.

VIDEO RESOURCES

IRIS MX Key Features

  • MOTION AMPLIFICATION®

    See motion invisible to the naked eye in near real-time view.

  • TIME WAVEFORMS, SPECTRA, AND ORBITS

    Unlimited number of regions can be drawn in the video to measure displacement. All measurements are simultaneous.

  • STABILIZATION

    Entire frame and region based image stabilization.

  • DATA EXPORT

    Export waveform, spectra, orbits, and object paths to .csv file.

  • FREQUENCY FILTERING

    Bandpass, bandstop, lowpass, and highpass filtering of time waveform and video.

  • MOTION MAPS

    Show colorized image overlays of individual frequencies or overall motion.

  • TOP FREQUENCY FILTERING

    Automatically determine frequencies of interest and create multiple filtered data sets with a single click.

  • SHAFT DISPLACEMENT

    Measure the displacement of a rotating shaft while under operation.

  • TRANSIENT MOTION AMPLIFICATION®

    See Motion Amplification® of small motions as an object moves through the scene.

  • TRANSIENT PATH PLOT

    Show the path of an object in the video as well as in the plot.

  • VIDEO ANNOTATIONS

    Add text, shape, annotations, and company logo overlays with export to video.

  • VIDEO SIDE-BY-SIDE

    Side-by-side playback of original and Motion Amplification® video.

IRIS MX SPECIFICATIONS

  • Lenses

    6mm, 12mm, 25mm, 50mm, 100mm.* *Lenses listed include M and MX hardware.

  • AQUISITION SYSTEM

    i7 processor, 16GB RAM, 500 GB SSD, dual batteries, lightweight, MIL-STD-810G standard drop protection, 3 yr accidental damage protection.

  • SAMPLE RATE

    1,400 fps in HD, up to 29,000 fps at reduced resolution.

  • FREQUENCY RANGE

    Up to 42,000 CPM at 180 fps Maximum: 870,000 CPM at 29,000 fps with reduced resolution.

  • MINIMUM DISPLACEMENT

    <0.01 mils (0.25 µm) at 3.3 ft (1m) with 50mm lens, 0.005 mils (0.125 µm) at close focus.

  • PLAYBACK/EXPORT SPEEDScessory Kit

    4x original framerate to 1 fps.

  • MOTION AMPLIFICATION® FACTOR

    1-500x

  • USB3 TO ETHERNET CABLE

    9.84 ft (3m)

  • OPTIONAL ACCESSORY KIT

    LED light: 23,000 Lux @ 1 m, Li-ion light battery, light stand, extra vibration pads, computer stand.

OUR PRODUCTS

IRIS MTM

  • Live Motion Amplification®
  • Calibrated Displacement Measurements
  • Frequency Based Filtering
  • Advanced Troubleshooting
LEARN MORE

IRIS MXTM

  • Motion Amplification®
  • Up to 1400 FPS in HD Resolution
  • Calibrated Displacement Measurements
  • Available as an Add On
LEARN MORE

IRIS CMTM

  • Live Motion Amplification®
  • Multiple Synchronized Cameras
  • Continuous Monitoring
  • Event and Threshold Triggering
LEARN MORE
